Wallbord Type Toilet Tissue Paper Making Machine

Fully Automatic Wallboard Structure Toilet Tissue Paper Plant Line
Key Features & Production Capabilities
Integrated Functions: Combines jumbo roll unwinding, embossing (steel-to-rubber or steel-to-steel), perforation, tail gluing, automatic log rewinding, and core loading.

PLC & Frequency Control: Equipped with programmable logic control (PLC), touch-screen interface, and variable frequency drive (VFD) for continuous, automated operation.

Pneumatic Control: Air cylinders control web tension, embossing engagement, and perforating unit pressure.

Safety & Precision: Solid side plates ensure accurate gear meshing, precise perforation blade alignment, and safer high-speed web transport.

Wallboard Type Toilet Tissue Paper Making Machine (or Wallboard-Structure Tissue Machine) structural design is the industry standard for medium-to-high-speed tissue production lines, providing enhanced structural stability, lower vibration, and higher precision.

Automatic Wallboard Type Toilet Paper Rewinder with Embossing Line Technical Specifications
Jumbo Roll Width: 1200 mm – 2800 mm (customizable depending on production scale).
Jumbo Roll Diameter: Up to 1200 mm – 1500 mm.
Finished Roll Diameter: 70 mm – 150 mm (adjustable).
Perforation Pitch: 90 mm – 120 mm (customizable blade configuration).
Design Speed: 180 m/min – 300 m/min.
Power Requirement: 7.5 kW – 22 kW (varies by width and automation level).
